Beschreibung
• The Triple-R light bar range brings motorsport and world rally performance to the off-road market. Compared with the equivalent 'drive' optic (T24) product, the Triple-R 24 delivers 5x the peak intensity to deliver a mid-long range LED solution which leaves little to the imagination for all night-time off-road driving and recreational use.
• Tuned for a spot beam pattern, while still achieving a decent spread of light in the mid-long range, the Triple-R 24 comprises 24 high power LEDs producing 24,600 lumens at only 270 watts. The light delivers 1 lux at an awe-inspiring distance of 1100m; while at 44” in length, the light is the perfect match of maximum illumination with feasible mounting options for many off-road vehicles. Through the use of the Triple-R Reeded Lens system, the beam pattern can be easily tailored to provide additional spread when, or if, required.
• Comprising our unique vacuum metallised hooded reflector system (with 100% light utilisation), a CAE optimised heatsink, and electronic thermal management system, the light output from the Triple-R 24 is optimised at all times. Furthermore, the rear-facing orientation of the LEDs reduces ‘scatter’ and enhances lighting performance in environments where fog or dust is prevalent.
• As with all Lazer products, we design our products in-house utilising the latest and most advanced component technologies to maximise performance and reliability. The unique styling of the Triple-R range alongside a fully aluminium enclosure, gore-tex breather membrane, and virtually unbreakable polycarbonate lens cover, means the Triple-R 24 will look good in even the toughest of environments.
• The light comes supplied with vehicle wiring kit and both side brackets and sliding centre mounts, to ensure maximum flexibility and ease of vehicle fitment. For off-road driving the Triple-R 24 delivers a level of lighting performance which needs to be seen to be believed.
Parameters
What's included:
• x1 Triple-R 24 Elite LED Lamp
• x2 Special Mount for Fixing, with the needed Screws
• x1 Wiring Harness, with Switch and Relay
Technical data: | |
Voltage Range | 10-32V |
LED Life | 50,000 hours |
Weight | 4.14 kg |
High beam function | |
Total Luminous Flux | 27060 Lm |
Colour Temperature | 5000k |
Number of High Output LEDs | 24 |
Power Consumption | 312 Watts |
Current Draw (at 14.4V) | 21.7 Amps |
Certification | |
High Beam | Not certified |
E-Mark Ref | Not certified |
Dimensions | |
Width | 1125 mm |
Depth | 105 mm |
Height | 73 mm |
Photometric data | |
0.25 lx Line | 2352 metres |
0.5 lx Line | 1663 metres |
1 lx Line | 1176 metres |
3 lx Line | 679 metres |
Beam spread | |
Horizontal | 30 degree spread |
Vertical | 15 degree spread |
