Parameters
What's included:
• x2 Triple-R 750 Standard LED Sportlights
• x1 Mounting Kit (comprising 4x Brackets and fasteners)
• x1 Two-Lamp Wiring Kit
• x1 Installation Instructions
| Based on standard setup i.e. x2 Triple-R 750 Standard LED Lamps: | ||
| Voltage Range | 10-32V | |
| LED Life | 50,000 hours | |
| Weight | 2 kg | |
| HIGH BEAM FUNCTION | ||
| Total Luminous Flux | 9240 Lm | |
| Colour Temperature | 5000k | |
| Number of High Output LEDs | 2 x 4 | |
| Power Consumption | 88 Watts | |
| Current Draw (at 14.4V) | 6.2 Amps | |
| CERTIFICATION | ||
| High Beam | ECE R112 | |
| ECE Reference | 35 x2 | |
| Photometric data | ||
| 0.25 lx Line | 1225 metres | |
| 0.5 lx Line | 866 metres | |
| 1 lx Line | 612 metres | |
| 3 lx Line | 354 metres | |
| Beam spread | ||
| Horizontal | 19 degree spread | |
| Vertical | 18 degree spread | |
